Dnevnik Ane Polanšćak – iliti kako sam dobila prvi People’s Choice Award
array(2) { ["Article"]=> array(10) { ["id"]=> string(3) "185" ["member_id"]=> string(2) "54" ["title_eng"]=> string(74) "Diary of Ana Polanšćak – or how I got my first People’s Choice Award" ["title_hrv"]=> string(78) "Dnevnik Ane Polanšćak – iliti kako sam dobila prvi People’s Choice Award" ["mask_eng"]=> string(65) "diary_of_ana_polanscak_or_how_i_got_my_first_peoples_choice_award" ["mask_hrv"]=> string(69) "dnevnik_ane_polanscak_iliti_kako_sam_dobila_prvi_peoples_choice_award" ["content_eng"]=> string(5464) "Ana Polanšćak, 21.07.2021.MONDAY, 6.7.2009.
Many months ago I started sculpting this huge bipedal bull, and recently I finally got tired of it standing on the shelf unfinished. After a few days of hanging out with greystuff and various beats, I came to this result:
And then I started painting him in hopes of getting him to finish it by Black Queen. This is what it currently looks like:
There is still a lot of work around him, but I hope to be finished by Saturday. I still have no idea for the base, if anyone has any suggestions.
WEDNESDAY, 8.7.2009.
THURSDAY, 9.7.2009.
A little more progress. I think I'll be able to finish it. I can't get to work on it today, so I still have tomorrow to fix everything I need and finish the base. If I had remembered earlier it would have been better, but can’t be helped now.
SATURDAY, 11.7.2009.
I thank everyone who voted for him to receive the People’s Choice Award.
" ["content_hrv"]=> string(5387) "
PONEDJELJAK, 6.7.2009.
Prije mnogo mjeseci pocela sam sa skulptiranjem ovog ogromnog bipedalnog bika, i nedavno mi je napokon dosadilo sto stoji na polici nedovrsen. Nakon nekoliko dana druzenja s greystuffom i raznim bitsevima dosla sam do ovog rezultata:
I onda sam ga pocela bojati u nadi da cu stici dovrsiti ga do Black queena. Ovako trenutno izgleda:
Oko njega ima jos dosta posla, nadam se da cu stici do subote. Jos uvijek nemam ideje za bazu, ako netko ima nek predlozi.
SRIJEDA, 8.7.2009.
ČETVRTAK, 9.7.2009.
Jos malo napretka. Mislim da cu stici dovrsiti ga. Danas vise ne stignem raditi, znaci ostaje mi jos sutra za popraviti sve kaj treba i srediti bazu. Da sam se ranije sjetila bolje bi ispao, ali kaj je tu je.
SUBOTA, 11.7.2009.
Zahvaljujem svima koji su glasali za njega da dobije People's choice award.
